• Vario (V)-Electronics for working at customised speeds to suit various application materials
• Thumbwheel for Speed Preselection
• Forward and reverse rotation
• Spindle with hexagonal recess for screwdriver bits for working without chuck

Characteristics

Rated input power

650 W

Output power

320 W

Maximum torque

10 Nm // 88 in-lbs

Drill-Ø masonry

16 mm / 5/8 "

Drill-Ø concrete

14 mm / 9/16 "

Drill Ø steel

13 mm // 1/2 "

Drill-Ø soft wood

30 mm // 1 3/16 "

Revolutions at rated load

1500 rpm

Maximum impact rate

44800 bpm

Gears

1

Chuck capacity

1.5 - 13 mm // 1/16 - 1/2 "

Collar diameter

43 mm / 1 11/16 "

Drill spindle with hexagonal recess

6.35 mm / 1/4 "

Drill spindle thread

1/2 " - 20 UNF

Chuck clamping type

Geared Chucks

Weight (without power cable)

1.8

Cable length

2.5 m / 8 ft

Vibration

Drilling in metal

5.8 m/s²

Uncertainty of measurement K

1.5 m/s²

Impact drilling concrete

24.4 m/s²

Uncertainty of measurement K

1.5 m/s²

Noise emission

Sound pressure level

91 dB(A)

Sound power level (LwA)

102 dB(A)

Uncertainty of measurement K

3 dB(A)
